ALL CATEGORIES   Semiconductor Mfg Eq   Physical Vapor Dep   PVD Power Supplies    View    Search-by-Specs    Input    Edit


in Radio Frequency (RF) Generators
Deal directly with Owner:  Capovani Brothers Inc. of Scotia, New York
Item ID: 179019

Offered 6 Offered at Best Price


RF Generator
Part number 9600610028.

You may also be interested in Seren MC2 Matching Network Controller

  Click to see additional image(s)... other images

Location: Scotia, New York
Unit Price Unstated
Number of Units 6
Manufacturer Seren
Model R601
Description RF Generator
Rated Power Output 600 Watts
Frequency 13.56
Scale MHz
Mismatched Power Output 100.00  W
Output Connector Type N
Panel Meters Digital
External Cooling Air Cooled
Other Information

Part number 9600610028.
This part number has analog interface connector pin 3 "RFON" modified, it will turn RF "ON" when pulled up to +24V.

If your application require standard unit (pin 3 internally pulled up to +5V, and will turn RF "ON" when pulled to the ground),

request conversion to the standard unit P/N 9600610000 when ordering, please.

Input power: 90-125 VAC or 190-264 VAC, 47-63 Hz (universal input).  Maximum current: 15A. There are no transformer voltage taps to configure.

Extended Description  Details at 6100220000_R(L)X01_Series_OPER_MAN_V1_04.pdf
Power Requirements 120/240 V     15.0 A     47-63 Hz     1¬†Phase
Year of Manufacture 2007
Exterior Dimensions
  Width 9.500  in  (24.1 cm)
  Depth 18.500  in  (47.0 cm)
  Height 7.000  in  (17.8 cm)
Weight 33  lb  (15 kg)
