|Other Information ||Catalog No.: 370501-A0A-T1.|
Power requirements: 90V to 130V or 180V to 240V
Two ion gauge sequential operation
Two setpoint process control 370108
RS232 communications 370110
Cables and gauges not included(inquire about availability)
Click here for the data sheet
Click here for the manual
There is a minor defect on the dot matrix LCD display of the ion gauge module behind the front door, does not affect the operation.
This controller can be calibrated for different ion gauges, calibration for each channel is loaded via memory modules.
If you have Stabil-Ion gauge with individual module containing calibration for that gauge, you should upload that to the controller before using it.
If you have standard Bayard-Alpert glass gauge, you need to upload average calibration for that type of the gauge with sensitivity 10/Torr to channel one, two or both.
Memory modules can be puchased from MKS Instruments
