|Other Information ||This controller can be calibrated for different ion gauges, calibration for each channel is loaded via memory modules.|
- If you have standard Bayard-Alpert glass gauge, CBI can upload average calibration for that gauge with sensitivity 10/Torr to channel one, two or both.
- If you have Stabil-Ion gauge with individual module containing calibration for that gauge, you should upload that to the controller before using it.
Specify type and sensitivity of your gauges when ordering.
- If you have Stabil-Ion gauge without individual module, CBI can upload average calibration with sensitivity 50/Torr to channel one, two or both.
Features and controls: Two ion gauges in sequential operation
One Convectron gauge
Electron Beam Degas
Click here for the manual
